Roland SG2-640 Colour Printer

TrueVIS large format inkjet printer/cutters have won multiple awards for their eye-opening colour and image quality that helps you stand out from the competition. With Japanese engineering and uncompromising attention to detail, the SG2 is designed for creative and dedicated professionals like you, who require quality, dependability, and versatility to build new levels of profit and success.

From £12,499+VAT

Spread your payments with our Leasing and Finance facilities.

Leasing from £61.50 per week +VAT

Download Brochure

Notice: Most inks, toners and consumables have expiry dates, please bear this in mind if ordering in bulk!

Forever transfers papers are only suitable for use with LASER PRINTERS.

Description

TrueVIS Printer/Cutters

Choose SG2-640 Printer / Cutters for Large Format Applications

Looking for the latest Roland inkjet technology to take your graphics to the next level? Expand your sign, vehicle graphics, commercial print, or other customization business with a cost-effective and reliable printer/cutter that provides premium graphics output. Available in 64” and 54” models, here are just some of the profitable large-format applications of the SG2-640.

New generation TrueVIS SG2 series large format printer/cutters provide the superior colour and cutting features you expect to find in a top-of-the-line machine but without the higher price tag.

Featuring new TR2 ink for a wider color gamut with brilliantly vivid print output at a very low ink cost per sq/ft

Offering smart new print/cut features that include automated pinch rollers

3M™ MCS™ Warranty and Avery Dennison™ ICS™ Warranty Program certified for added print confidence

PerfCut Mode
Print, cut, and die-cut with ultimate ease using easy perf-cutting tools. Advanced SG2 and VersaWorks 6 RIP software combine to make batching stickers and decals a simpler process.

New Crop Mark Features
With a few easy clicks, you can improve accuracy on long print runs of stickers, heat transfers, and more with custom cropping and the new Crop Mark by Row function in VersaWorks 6 software. When handling intricate files, you can also select Crop Mark by Image.

Improved workflow
With faster job setup time and sequence, reduced ink maintenance consumption, and other productivity features, the SG2 offers added usability and performance.

Nozzle Mask Function
If a nozzle on the printhead is clogged and misfiring, you can turn off a specific nozzle band and carry-on printing.

Optional Media Take-Up
An optional new TUC4 take-up system offers smooth and stable production— it has two modes to handle everything from adhesive-backed vinyl to thicker media like canvas and banner.

Roland DG Mobile Panel
Clean, test print and troubleshoot your SG2 from the comfort of your tablet or smartphone with Bluetooth enabled printer management.

Built to Build Your Business
TrueVIS large format inkjet printer/cutters have won multiple awards for their eye-opening colour and image quality that helps you stand out from the competition. With Japanese engineering and uncompromising attention to detail, the SG2 is designed for creative and dedicated professionals like you, who require quality, dependability, and versatility to build new levels of profit and success.

Roland BLI Buyers Lab 2020 Pick Logo on transparent background

TrueVIS SG2 outshines competitors in independent tests

The TrueVIS SG2-640 and SG2-540 have earned top honours in the prestigious Keypoint Intelligence Buyers Lab 2020 Pick Awards for Outstanding Entry-Level CMYK (Eco-solvent/Latex 54”/64” Printer category).

The award, from the industry’s leading independent global provider of testing and analysis, reflects the incredible print quality and superb usability of the SG2.

Bring Your Graphics To Life With Detail, Colour and Excitement

TrueVIS SG2 produces exceptional quality graphics, in vibrant yet natural colours which truly stand out from the crowd. With enhanced Print & Cut accuracy and improved production efficiency you can produce die-cut decals and labels, eye-catching banners, striking signs, vibrant vehicle wraps – and so much more.

Van outside with Victoria flowers branding wrap, made with Roland True Vis SG2 Series Printers
Roland True Rich Colour SG2 Series Diagram on transparent background

Enhance your Business with True Rich Color

A new colour management preset, True Rich Color, takes full advantage of the SG2 series’ impressive colour reproduction capability and the wider colour gamut provided by TR2 ink. Now vibrant colours can be combined with neutral greys, smooth gradations, and natural skin tones to create stunning graphics.

SG2-640SG2-540SG2-300
Printing methodPiezo ink-jet method
MediaWidth12.4 to 64 in. (315 to 1,625 mm)10.8 to 54 in. (275 to 1,371 mm)182 to 762 in. (182 to 762 mm)
ThicknessMax. 39 mil (1.0 mm) with liner, for printing
Max. 16 mil (0.4 mm) with liner and 9 mil (0.22 mm) without liner, for cutting
Roll outer diameterMax. 8.3 in. (210 mm )
Roll weightMax. 88 lb. (40 kg)Max. 66 lb. (30 kg)Max. 55 lb. (25 kg)
Core diameter (*1)3 in. (76.2 mm) or 2 in. (50.8 mm)
Printing/cutting width (*2)Max. 63 in. (1,600 mm)Max. 53 in. (1,346 mm)Max. 29 in. (736 mm)
InkTypeTrueVIS INK 500 ml pouch
ColorsFour colors (cyan, magenta, yellow, and black)
Printing resolution (dots per inch)Max. 1,200 dpi
Cutting speed0.4 to 11.8 in/s (10 to 300 mm/s)
Blade force (*3)30 to 500 gf
BladeTypeRoland CAMM-1 series blade
Offset0.0 to 59.1 mil (0.000 to 1.500 mm)
Software resolution (when cutting)0.98 mil/step (0.025 mm/step)
Distance accuracy (when printing) (*4) (*5)Error of less than ±0.3% of distance traveled or ±11.8 mil (±0.3
mm), whichever is greater
Distance accuracy (when cutting) (*4)Error of less than ±0.4% of distance traveled or ±11.8 mil (±0.3
mm), whichever is greater
When distance correction has been performed (when the setting for [CUTTING MENU] – [CALIBRATION] has
been made): Error of less than ±0.2% of distance traveled or ±3.9 mil (±0.1 mm),
whichever is greater
Repeatability (when cutting) (*4) (*6)±3.9 mil (±0.1 mm) or less
Alignment accuracy for printing and cutting (*4) (*7)±19.7 mil (±0.5 mm) or less
Alignment accuracy for printing and cutting when reloading media (*4) (*8)Error of less than ±0.5% of distance traveled, or ±0.2 in. (±3 mm),
whichever is greater
Media heating system (*9)Print heater set temperature: 86 to 112°F (30 to 45°C)
Dryer set temperature: 30 to 50°C (86 to 122°F)
ConnectivityEthernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving functionAutomatic sleep feature
Power requirementsAC 100 to 120 V ±10%, 8.0 A, 50/60 Hz or
AC 220 to 240 V ±10%, 4.1 A, 50/60 Hz
AC 100 to 120 V ±10%, 5.4 A, 50/60 Hz or
AC 220 to 240 V ±10%, 2.7 A, 50/60 Hz
Power consumptionDuring operationApprox. 1,090 WApprox. 710 W
Sleep modeApprox. 40 W
Acoustic noise levelDuring operation63 dB (A) or less
During standby53 dB (A) or less
Dimensions (with stand)116 [W] × 28.8 [D] × 51.6 [H] in.
(2,945 (W) × 730 (D) × 1,310 (H) mm)
105.8 [W] × 28.8 [D] × 51.6 [H] in.
(2,685 (W) × 730 (D) × 1,310 (H) mm)
81.5 [W] × 28.8 [D] × 51.6 [H] in.
(2,070 (W) × 730 (D) × 1,310 (H) mm)
Weight (with stand)434 lb. (197 kg)397 lb. (180 kg)324 lb. (147 kg)
EnvironmentDuring operationTemperature: 68 to 90°F (20 to 32°C),
Humidity: 35 to 80%RH (no condensation)
Not operatingTemperature: 41 to 104°F (5 to 40°C),
Humidity: 20 to 80%RH (no condensation)
Included itemsDedicated stands, power cord, media clamps, media holders, replacement blade for
separating knife, manuals, etc.
