Roland SG2-540 Colour Printer
TrueVIS large format inkjet printer/cutters have won multiple awards for their eye-opening colour and image quality that helps you stand out from the competition. With Japanese engineering and uncompromising attention to detail, the SG2 is designed for creative and dedicated professionals like you, who require quality, dependability and versatility to build new levels of profit and success.
OUT OF STOCK
Spread your payments with our Leasing and Finance facilities.
Roland SG2 Wide Format Printer
Looking for the latest Roland inkjet technology to take your graphics to the next level? Expand your sign, vehicle graphics, commercial print or other customization business with a cost-effective and reliable printer/cutter that provides premium graphics output. Available in 64” and 54” models, here are just some of the profitable large format applications of the SG2-540.
New generation TrueVIS SG2 series large format printer/cutters provide the superior colour and cutting features you expect to find in a top-of-the-line machine, but without the higher price tag.
Featuring new TR2 ink for a wider colour gamut with brilliantly vivid print output at a very low ink cost per sq/ft
Offering smart new print/cut features that include automated pinch rollers
3M™ MCS™ Warranty and Avery Dennison™ ICS™ Warranty Program certified for added print confidence
Print, cut, and die-cut with ultimate ease using easy perf-cutting tools. Advanced SG2 and VersaWorks 6 RIP software combine to make batching stickers and decals a simpler process.
With faster job setup time and sequence, reduced ink maintenance consumption, and other productivity features, the SG2 offers added usability and performance.
Roland DG Mobile Panel
Clean, test print, and troubleshoot your SG2 from the comfort of your tablet or smartphone with Bluetooth enabled printer management.
Built to Build Your Business
TrueVIS large format inkjet printer/cutters have won multiple awards for their eye-opening colour and image quality that helps you stand out from the competition. With Japanese engineering and an uncompromising attention to detail, the SG2 is designed for creative and dedicated professionals like you, who require quality, dependability and versatility to build new levels of profit and success.
TrueVIS SG2 outshines competitors in independent tests
The TrueVIS SG2-640 and SG2-540 have earned top honours in the prestigious Keypoint Intelligence Buyers Lab 2020 Pick Awards for Outstanding Entry-Level CMYK (Eco-solvent/Latex 54”/64” Printer category).
The award, from the industry’s leading independent global provider of testing and analysis, reflects the incredible print quality and superb usability of the SG2.
Bring Your Graphics To Life With Detail, Colour, and Excitement
TrueVIS SG2 produces exceptional quality graphics, in vibrant yet natural colours which truly stand out from the crowd. With enhanced Print & Cut accuracy and improved production efficiency you can produce die-cut decals and labels, eye-catching banners, striking signs, vibrant vehicle wraps – and so much more.
Enhance your Business with True Rich Colour
A new colour management preset, True Rich Colour, takes full advantage of the SG2 series’ impressive colour reproduction capability and the wider colour gamut provided by TR2 ink. Now vibrant colours can be combined with neutral greys, smooth gradations and natural skin tones to create stunning graphics.
|Printing method||Piezo ink-jet method|
|Media||Width||12.4 to 64 in. (315 to 1,625 mm)||10.8 to 54 in. (275 to 1,371 mm)||182 to 762 in. (182 to 762 mm)|
|Thickness||Max. 39 mil (1.0 mm) with liner, for printing
Max. 16 mil (0.4 mm) with liner and 9 mil (0.22 mm) without liner, for cutting
|Roll outer diameter||Max. 8.3 in. (210 mm )|
|Roll weight||Max. 88 lb. (40 kg)||Max. 66 lb. (30 kg)||Max. 55 lb. (25 kg)|
|Core diameter (*1)||3 in. (76.2 mm) or 2 in. (50.8 mm)|
|Printing/cutting width (*2)||Max. 63 in. (1,600 mm)||Max. 53 in. (1,346 mm)||Max. 29 in. (736 mm)|
|Ink||Type||TrueVIS INK 500 ml pouch|
|Colors||Four colors (cyan, magenta, yellow, and black)|
|Printing resolution (dots per inch)||Max. 1,200 dpi|
|Cutting speed||0.4 to 11.8 in/s (10 to 300 mm/s)|
|Blade force (*3)||30 to 500 gf|
|Blade||Type||Roland CAMM-1 series blade|
|Offset||0.0 to 59.1 mil (0.000 to 1.500 mm)|
|Software resolution (when cutting)||0.98 mil/step (0.025 mm/step)|
|Distance accuracy (when printing) (*4) (*5)||Error of less than ±0.3% of distance traveled or ±11.8 mil (±0.3
mm), whichever is greater
|Distance accuracy (when cutting) (*4)||Error of less than ±0.4% of distance traveled or ±11.8 mil (±0.3
mm), whichever is greater
When distance correction has been performed (when the setting for [CUTTING MENU] – [CALIBRATION] has
been made): Error of less than ±0.2% of distance traveled or ±3.9 mil (±0.1 mm),
whichever is greater
|Repeatability (when cutting) (*4) (*6)||±3.9 mil (±0.1 mm) or less|
|Alignment accuracy for printing and cutting (*4) (*7)||±19.7 mil (±0.5 mm) or less|
|Alignment accuracy for printing and cutting when reloading media (*4) (*8)||Error of less than ±0.5% of distance traveled, or ±0.2 in. (±3 mm),
whichever is greater
|Media heating system (*9)||Print heater set temperature: 86 to 112°F (30 to 45°C)
Dryer set temperature: 30 to 50°C (86 to 122°F)
|Connectivity||Ethernet (100BASE-TX/1000BASE-T, automatic switching)|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 120 V ±10%, 8.0 A, 50/60 Hz or
AC 220 to 240 V ±10%, 4.1 A, 50/60 Hz
|AC 100 to 120 V ±10%, 5.4 A, 50/60 Hz or
AC 220 to 240 V ±10%, 2.7 A, 50/60 Hz
|Power consumption||During operation||Approx. 1,090 W||Approx. 710 W|
|Sleep mode||Approx. 40 W|
|Acoustic noise level||During operation||63 dB (A) or less|
|During standby||53 dB (A) or less|
|Dimensions (with stand)||116 [W] × 28.8 [D] × 51.6 [H] in.
(2,945 (W) × 730 (D) × 1,310 (H) mm)
|105.8 [W] × 28.8 [D] × 51.6 [H] in.
(2,685 (W) × 730 (D) × 1,310 (H) mm)
|81.5 [W] × 28.8 [D] × 51.6 [H] in.
(2,070 (W) × 730 (D) × 1,310 (H) mm)
|Weight (with stand)||434 lb. (197 kg)||397 lb. (180 kg)||324 lb. (147 kg)|
|Environment||During operation||Temperature: 68 to 90°F (20 to 32°C),
Humidity: 35 to 80%RH (no condensation)
|Not operating||Temperature: 41 to 104°F (5 to 40°C),
Humidity: 20 to 80%RH (no condensation)
|Included items||Dedicated stands, power cord, media clamps, media holders, replacement blade for
separating knife, manuals, etc.
